图文名称：变矩器 52C0002
所属机型：CLG852
图文编号：324
物料编号：52C0002（ZL50C.3.3）
|
 |
|
| 详细资料 |
|
序号
Sr.No |
零件号
Part No |
旧零件号
Old Part No |
名称
Nomenclature |
规格
Size |
数量
Q’ty |
|
1 |
10A0010 |
ZL50C.3.3-1 |
弹性板 |
Flexible Disc |
|
1 |
|
2 |
47A0002 |
ZL50C.3.3-2 |
罩轮 |
Pump Cover |
|
1 |
|
3 |
05B0004 |
ZL50C.3.3-3 |
螺柱 |
Stud |
|
12 |
|
4 |
52C0003 |
ZL50C.3.3.1 |
涡轮组 |
Turbine Groud |
|
1 |
|
5 |
56A0004 |
ZL50C.3.3-4 |
圆垫板 |
Retaining Plate |
|
1 |
|
6 |
00B0040 |
GB5783-86 |
螺栓 |
Bolt |
M12X25 |
6 |
|
7 |
06B0008 |
GB93-87 |
垫圈 |
Washer |
12 |
18 |
|
8 |
21B0001 |
GB/T276-94 |
球轴承 |
Ball Bearing |
6210 |
1 |
|
9 |
01B0003 |
GB5782-86 |
螺栓 |
Bolt |
M8X35 |
36 |
|
10 |
03B0021 |
GB6170-86 |
螺母 |
Nut |
M8 |
24 |
|
11 |
06B0006 |
GB93-87 |
垫圈 |
Washer |
8 |
44 |
|
12 |
03B0053 |
GB6170-86 |
螺母 |
Nut |
M10 |
12 |
|
13 |
06B0002 |
GB93-87 |
垫圈 |
Washer |
10 |
21 |
|
14 |
01B0004 |
GB5782-86 |
螺栓 |
Bolt |
M12X45 |
11 |
|
15 |
81A0005 |
ZL50C.3.3-5 |
垫 |
Pad |
|
1 |
|
16 |
12D0002 |
ZL50C.3.3.2 |
弹性板总成 |
Flexible Disc |
|
1 |
|
17 |
00B0007 |
GB5783-86 |
螺栓 |
Bolt |
M8X16 |
8 |
|
18 |
11A0011 |
ZL50C.3.3-6 |
垫板 |
Pad |
|
1 |
|
19 |
82A0004 |
ZL50C.3.3-7 |
衬垫 |
Pad |
|
1 |
|
21 |
70A0001 |
ZL50C.3.3-8 |
壳体 |
Converter Casing |
|
1 |
|
22 |
47A0003 |
ZL50C.3.3-9 |
导向轮 |
Stator |
|
1 |
|
23 |
21B0002 |
GB276/T-94 |
球轴承 |
Ball Bearing |
6017 |
2 |
|
24 |
00A0170 |
ZL50C.3.3-10B |
油温表接头 |
Joint |
|
1 |
|
25 |
41A0004 |
ZL50C.3.3-11 |
齿轮 |
Gear |
|
1 |
|
26 |
80A0006 |
ZL50C.3.3-13 |
密封环 |
Seal Ring |
|
1 |
|
27 |
00B0012 |
GB5783-86 |
螺栓 |
Bolt |
M10X25 |
9 |
|
序号
Sr.No |
零件号
Part No |
旧零件号
Old Part No |
名称
Nomenclature |
规格
Size |
数量
Q’ty |
|
28 |
61A0018 |
ZL50C.3.3-12 |
导轮座 |
Stator Support |
|
1 |
|
29 |
12B0144 |
GB1235-76 |
0形圈 |
“O”Ring |
32×3.1 |
2 |
|
30 |
03A0019 |
BB70-9 |
管接头 |
Connector |
|
2 |
|
31 |
05A0008 |
ZL50C.3.3-24 |
堵头 |
Plug |
|
1 |
|
32 |
07B0001 |
GB894.1-86 |
挡圈 |
Retainer Ring |
85 |
1 |
|
33 |
56A0005 |
ZL50C.3.3-14 |
压紧垫片 |
Clamp |
|
1 |
|
34 |
47A0004 |
ZL50C.3.3-15 |
泵轮 |
Pump Wheel |
|
1 |
|
35 |
21A0005 |
ZL50C.3.3-16 |
阀盖 |
Valve Cover |
|
1 |
|
36 |
10B0001 |
ZL50C.3.3-17 |
弹簧 |
Spring |
|
1 |
|
37 |
13A0011 |
ZL50C.3.3-18 |
压板 |
Clamp |
|
1 |
|
38 |
10B0002 |
ZL50C.3.3-19 |
弹簧 |
Spring |
|
1 |
|
39 |
65A0001 |
ZL50C.3.3-20 |
阀杆 |
Valve Stem |
|
1 |
|
40 |
65A0002 |
ZL50C.3.3-21 |
阀杆 |
Valve Stem |
|
1 |
|
41 |
12B0207 |
GB1235-76 |
0形圈 |
“O”Ring |
22×2.4 |
1 |
|
42 |
03A0012 |
ZL50C.3.3-22 |
接头 |
Connector |
|
1 |
|
43 |
10A0013 |
ZL50C.3.3-23B |
铭牌“变矩器” |
Nameplate |
|
1 |
|
44 |
09B0002 |
GB827-86 |
铆钉 |
Rivet |
2×5 |
4 |
|
45 |
12B0143 |
GB1235-76 |
0形圈 |
“O”Ring |
30×3.1 |
1 |
|
46 |
57A0074 |
ZL50C.3.3-25A |
调整垫 |
Washer |
|
1组 |
|
47 |
00B0055 |
GB5783-86 |
螺栓 |
Bolt |
M12×40 |
1 |
|
48 |
57A0073 |
ZL50C.3.3-26 |
调整垫 |
Washer |
|
1组 |
|
49 |
12B0043 |
GB1235-76 |
0形圈 |
“O”Ring |
24×2.4 |
1 | |
|
|
|
|
| |
|
|
|
|
